IPX7 IPX8 Water Immersion Test Chamber

产品详情

Dexiang IPX7 IPX8 Water Immersion Test Chamber

Experience precision waterproof testing with the Dexiang IPX7 IPX8 Water Immersion Test Chamber. Designed for unmatched product reliability, this chamber ensures your devices meet the toughest water ingress standards.

Key Features at a Glance

IEC 60529-Compliant for IPX7 tests at 1 meter for 30 minutes
Supports IPX8 custom depths up to 2 meters for extended immersion
Spacious 500L stainless steel tank
Certified to CE and ISO 17025 standards

See It in Action

Explore the chamber’s durable exterior, advanced digital controls, and spacious immersion tank with our high-resolution image carousel. Watch how easy it is to set up and monitor your water ingress tests.

Ready to protect your electronics?

Request a Quote and start your journey to flawless waterproof certification today.

Product Overview

Dexiang’s IPX7 8 Water Immersion Test Chamber is built to simulate tough underwater conditions, making sure your products stay water-tight and reliable. Whether you’re testing electronics, automotive parts, LED lighting, or outdoor gear, this chamber verifies enclosure integrity under real-world submersion stresses.

Key features include:

Durable stainless steel construction for lasting performance
Automated water level control for precise immersion
Pressure simulation up to 0.2MPa for IPX8 testing
Real-time monitoring via touchscreen interface

Watch our quick 1-2 minute demo to see how easy it is to set up, run a test cycle, and interpret results for confident waterproof certification.

Technical Specifications

Model Variants

Standard: Focused on IPX7 testing
Advanced: Supports both IPX7 and IPX8, includes hoist for easy sample handling

Chamber Dimensions

Internal: 20” W × 20” D × 39” H (500 × 500 × 1000mm)
External: 31” W × 28” D × 59” H (800 × 700 × 1500mm)
Custom sizes available on request

Test Parameters

IPX7: 1 meter depth for 30 minutes immersion
IPX8: Depth from 1 to 3 meters, customizable time and pressure
Water Temperature: Ambient up to 104°F (40°C)

Materials and Controls

Durable SUS304 stainless steel tank
User-friendly PLC touchscreen interface
Features auto-fill and drain valves
Precise encoder-based depth gauge for accurate immersion depth

Power and Safety

Standard 220V, 50Hz power supply
Built-in overload protection and emergency stop
Equipped with anti-explosion venting for maximum safety

Compliance

Fully compliant with IEC 60529 and GB T 4208 standards
Uses UL-listed components to ensure reliability and safety

Key Features and Benefits

Precision Immersion Control

Our IPX7 8 Water Immersion Test Chamber uses encoder-driven depth adjustment to deliver exact IEC 60529 compliance. This means you get consistent, accurate submersion tests every time with up to 95% less variability. Your results stay reliable and repeatable, helping you meet strict waterproofing standards.

Dual-Mode Testing

Switch effortlessly between IPX7 and IPX8 testing modes. Whether you need a 1-meter, 30-minute test or customized deeper immersions, the chamber adapts smoothly. This flexibility speeds up workflows and lowers costs by letting you run multiple test types in one machine.

User-Friendly Design

The chamber features a clear viewing window so you can easily monitor tests in progress. Mobile casters make it simple to move around your lab or production floor. Plus, the built-in recirculation system cuts down water consumption by up to 70%, saving you money and reducing waste.

Durability and Maintenance

Built with corrosion-resistant stainless steel and easy-access panels, this immersion tank is made to last. Regular upkeep is straightforward. We back this with a 3-year warranty, giving you peace of mind for long-term use.

Benefits at a Glance

Accurate and repeatable waterproof testing
Versatile IPX7 IPX8 functionality for broader test range
Saves water and operational costs
Easy to use and maintain
Speeds up certification and quality control
Prevents costly product failures in the field

With Dexiang’s immersion test chamber, you boost your quality control process and confidently protect your products against water damage based on trusted IEC standards.

Applications and Use Cases

The Dexiang IPX7 IPX8 Water Immersion Test Chamber is ideal for a wide range of industries and products that require reliable waterproof testing. It’s perfect for electronics like smartphones, wearables, and other consumer gadgets. Automotive parts such as sensors and lighting also benefit from precise water ingress testing. We support LED fixtures and outdoor lighting, helping manufacturers ensure long-lasting durability. Marine equipment and outdoor gear that face tough wet conditions rely on our chamber for dependable immersion tests.

Real Results for LED Manufacturers

One LED lighting company used our chamber to achieve IP68 certification 20% faster than before. By reducing test variability and speeding up their quality control, they brought products to market quicker without sacrificing reliability.

Visual Test Scenarios

Check out our infographic showing battery enclosure submersion scenarios. It highlights how our chamber mimics real-world conditions to verify water resistance accurately, making it easier for you to understand where and how your products will be tested.

For more on water resistance and related test equipment, explore our IEC 60529 Compliant Chambers.

How It Works Step by Step Guide

Using the Dexiang IPX7 8 Water Immersion Test Chamber is simple and smooth. Here’s how you get your waterproof testing done right:

Place your sample securely in the basket hoist. This keeps your product stable during the test.
Set the depth and test time easily on the touchscreen control panel. Choose between IPX7, IPX8, or custom immersion settings.
The chamber auto-fills with water and begins the immersion test once you start the cycle.
Watch the test through the clear viewing window while the PLC system monitors everything in real-time for precision.
After the test, the chamber auto-drains safely, so you don’t have to worry about cleanup.
All test data is logged automatically, making it easy to generate accurate reports for your quality control or certification needs.

For added convenience, download the IPX7 IPX8 Testing Protocol Checklist PDF to keep your processes on track and compliant with IEC 60529 standards.

Why Choose Dexiang

Trusted Leader in Environmental Simulation

Since 2005, Dexiang has been a top name in environmental simulation, providing reliable, ISO-certified IPX7 and IPX8 water immersion test chambers. We back our products with worldwide customer support, ensuring you get expert help whenever you need it.

Dexiang vs Competitors

Feature	Dexiang	Competitors
Setup Time	Faster setup, ready in hours	Often takes days
Energy Efficiency	Lower energy use saves costs	Higher power consumption
Compliance	Full IEC 60529 and ISO 17025	Varies, less consistent
Support	24/7 global customer service	Limited regional support

What Our Clients Say

“Dexiang’s chamber streamlined our IPX8 validations, delivering flawless results every time.” — Electronics Firm Lead
“Thanks to Dexiang, we cut testing time and boosted reliability for our outdoor gear.” — Product Manager, Outdoor Equipment
“Their support team helped us customize the chamber to fit our unique testing needs perfectly.” — QA Director, Automotive Supplier

Choose Dexiang for precision, reliability, and support that keeps your IPX7 IPX8 waterproof testing running smoothly.

Pricing and Customization

Tiered pricing customizable environmental chambers

Our IPX7 8 Water Immersion Test Chamber starts at competitive pricing designed to fit different budget needs. For an accurate quote tailored to your specific requirements, please contact us directly.

You can customize your chamber with a variety of add-ons to make it perfect for your testing setup:

Extended warranty options for peace of mind
Custom tank sizes to fit larger products or specific testing depths
Integration with data loggers for advanced test reporting and tracking

Ready to build the right chamber for your lab? Use our Customize Your Chamber form to get started.

FAQs

What’s the difference between IPX7 and IPX8?

IPX7 means protection against water immersion up to 1 meter for 30 minutes. IPX8 offers deeper and longer immersion, usually beyond 1 meter, with time and depth set by the user.

How do I calibrate the depth sensor?

Calibration is simple with the PLC touchscreen. Follow on-screen prompts to set reference points, then validate by testing a known depth. Regular calibration keeps results accurate and compliance-ready.

What is the lead time for delivery?

Typical delivery is 4-6 weeks after order confirmation. Custom sizes or added features may extend lead time slightly.

Can I switch easily between IPX7 and IPX8 tests?

Yes, the chamber supports seamless switching between IPX7 and IPX8 modes through the control panel, saving setup time.

Is the water temperature adjustable during tests?

You can set water temperature from ambient up to 40°C to match real-world conditions.

Does the chamber support automated draining and refilling?

Yes, auto-fill and drain valves are built in for easy test cycle management and water saving.

Is there a warranty included?

The chamber comes with a 3-year warranty covering parts and service for peace of mind.

For more detailed answers, check the downloadable PDF [IPX7 IPX8 Testing Protocol Checklist].
