Adhesive tape Tensile Test Equipment
Professional tape tensile testing equipment, providing peel strength, initial adhesion and holding power tests, in compliance with standards such as ASTM D3330. It is suitable for adhesive performance testing of tapes in packaging, electronics and medical industries.
- Model ：DX-L201-5
- Capacity : 5, 10, 20, 25, 50, 100, 200kg
- Accuracy : ±0.5%
- Max. Stroke : 1000mm (including fixture)
- Test Speed ： 0.1-500mm/min (adjustable )
- Elongation Accuracy : 0.001mm
Product Details
Adhesive Tape Tensile Test Equipment Precision You Can Trust
Experience reliable, accurate testing with our advanced adhesive tape tensile test equipment designed for quality control and product development. From peel strength testers to release liner peel testers, our machines deliver consistent results that help you optimize tape performance and ensure compliance with industry standards.
Key Benefits
- High accuracy and repeatability for dependable data
- Servo motor driven for smooth, precise testing
- Interchangeable grips to handle various tape types
- Integrated software streamlines testing and reporting
- Safety features protect operators and equipment
![High Resolution Image of Adhesive Tape Tensile Test Equipment]
Ready to improve your tape testing process?
Request a Quote Today and get personalized support tailored to your testing needs.
Product Features and Innovations
Our Adhesive Tape Tensile Test Equipment stands out with advanced features designed for accuracy, ease, and safety. Here’s what you can expect:
- Servo Motor Drive: Smooth, precise control for every test.
- Interchangeable Grips: Easily switch grips for different tape types and sizes.
- Integrated Software: User-friendly interface with data analysis and reporting tools.
- Safety Features: Built-in emergency stop and protective covers for safe operation.
- Multi-Test Compatibility: Works seamlessly with Peel Strength Tester and Release Liner Peel Tester for versatile tape testing needs.
- High Accuracy Sensors: Ensures reliable results every time.
- Compact Design: Saves space without sacrificing functionality.
| Feature | Benefit |
|---|---|
| Servo Motor | Smooth and accurate test execution |
| Interchangeable Grips | Quick setup for multiple tape formats |
| Integrated Software | Easy data management and reporting |
| Safety Features | Operator protection and risk reduction |
| Brand Integration | Supports peel and release liner testing |
Together with our Peel Strength Tester and Release Liner Peel Tester, this equipment covers your full range of adhesive tape testing, from tensile strength to bond and peel performance.
Detailed Specifications
Our Adhesive tape Tensile Test Equipment is built for precision and flexibility. Check out the key specs below to see how it fits your testing needs.
| Feature | Specification |
|---|---|
| Load Capacity | Up to 500 N |
| Accuracy | ±0.5% |
| Test Speed Range | 1 to 500 mm/min |
| Standards Compliance | ASTM D3759, ISO 29862, PSTC Methods |
| Display | 7-inch touchscreen with real-time data |
| Grips | Interchangeable for various tape types |
| Software | Integrated analysis with data export |
| Power Supply | 110V/220V switchable |
| Safety Features | Emergency stop, overload protection |
| Accessories Included | Calibration weights, sample holders |
Customization Options
- Load ranges adjusted to fit particular materials
- Special grips available for unique tape sizes
- Software tailored for specific testing protocols
Calibration Certificate
Every machine comes with a traceable calibration certificate. We ensure your Adhesive bond strength analyzer meets industry standards from day one, giving your lab reliable and repeatable results.
How It Works Step by Step Guide
- Secure the SamplePlace your adhesive tape or release liner firmly into the interchangeable grips. The grips adjust easily to fit different tape widths for a tight hold.
- Set Test ParametersUse the integrated software on the touchscreen to select your test type, speed, and load limits. You can choose ASTM D3759 tensile test or other standards right from the menu.
- Start the TestPress start to let the servo motor pull the tape at a controlled speed. The machine measures tensile strength, peel strength, or shear adhesion depending on your setup.
- Monitor in Real TimeWatch the data graph and force curve update live on the screen as the test runs. The touchscreen lets you pause or stop anytime if needed.
- Analyze ResultsWhen the test finishes, get instant detailed results including peak force, elongation, and holding power. Save or export data reports for quality control.
- Watch Video DemoUse the built-in video playback to review your test in action or train new users. This feature improves accuracy and speeds up learning.
Our Adhesive tape Tensile Test Equipment and Peel Strength Tester make testing simple and reliable for U.S. manufacturers focused on fast, accurate quality checks.
Applications and Industry Use Cases
Our adhesive tape tensile test equipment is built to serve a wide range of industries, making it a versatile choice for quality control and product development in the U.S. market.
- Packaging: Test the durability and holding power of packaging tapes to ensure reliable sealing during shipping.
- Automotive: Measure adhesive bond strength for tapes used in automotive assembly and repair.
- Electronics: Evaluate pressure sensitive tape performance and peel strength on delicate electronic components.
- Medical: Verify the safety and durability of medical tapes and adhesives under various conditions.
Customer Feedback
“Our QC team cut testing time by 30% using Dexiang’s tensile and peel strength testers. It’s a real boost for productivity and quality assurance.” – Quality Manager, Midwest Packaging Co.
This adhesive bond strength analyzer helps you deliver consistent, trustworthy results that keep your business ahead in competitive markets.
Standards and Compliance
Our adhesive tape tensile test equipment meets all key industry standards to ensure reliable, accurate results every time. We support:
- ASTM D3759 – Standard Test Method for Tensile Strength of Pressure-Sensitive Tape
- ASTM D3330 – Adhesion to Flexible Backing Films
- ISO 29862 – Peel Test for Adhesive Tapes
- PSTC-1 – Peel Adhesion of Pressure-Sensitive Tape
- PSTC-7 – Loop Tack Test
You’ll see compliance icons displayed on our product materials, giving you confidence that your testing meets national and international benchmarks. This makes our equipment ideal for quality control, R&D, and manufacturing across the US market.
With certification-aligned testing, your tape’s peel strength, shear adhesion, and release liner performance data are trusted, consistent, and industry-recognized.
Why Choose Dexiang
At Dexiang, we’re all about trust and quality. We’ve been manufacturing adhesive tape tensile test equipment right here for the U.S. market, focusing on reliability and accuracy. Our gear comes backed with a solid warranty and a support team that’s ready to help when you need it—no long wait times or confusing tech talk.
Our Promise
- Industry-leading warranty on all Adhesive tape Tensile Test Equipment
- Responsive customer support based in the U.S.
- Free calibration and custom setup options to fit your testing needs
Dexiang vs Competitors
| Feature | Dexiang | Competitors |
|---|---|---|
| Warranty | 2 Years | 1 Year |
| Local Support | U.S.-based, fast response | Often overseas, slower |
| Calibration Certificate | Included | Extra cost |
| Software | Integrated and user-friendly | Optional, less intuitive |
| Certification | CE, ISO 9001 Certified | Limited or none |
Certified Quality You Can Count On
- CE Certified: Meets all essential safety and performance requirements
- ISO 9001 Certified: Ensures consistent quality management and product excellence
Choosing Dexiang means you get proven performance, straightforward warranties, and real people supporting your equipment. We make sure your adhesive tape tensile tests run smoothly from start to finish.
Pricing Options and Accessories
We offer flexible pricing plans designed to fit your budget and testing needs. Whether you’re a small business or a large manufacturer, you can choose the right Adhesive Tape Tensile Test Equipment package.
| Pricing Tier | Features Included | Best For |
|---|---|---|
| Basic | Standard tester with peel strength capabilities | Small labs, entry-level testing |
| Professional | Servo motor, interchangeable grips, full software | Mid-size businesses |
| Enterprise | All features plus customization and on-site support | Large scale production |
Get a personalized quote by clicking the request a quote button.
Accessories and Cross Sell Products
Enhance your testing setup with these add-ons:
| Accessory | Description | Purpose |
|---|---|---|
| Peel Strength Tester | Additional unit for quick peel tests | Increase testing capacity |
| Release Liner Peel Tester | Specialized device for release liner analysis | Improve accuracy on liners |
| Packaging Tape Shear Tester | Tests shear adhesion of packaging tapes | Ensure durability in shipping |
| Calibration Kit | For regular equipment calibration | Maintain test accuracy |
Need help picking the right package or accessories? Contact our team for expert advice tailored to your industry.
Customer Support and Resources
We’re here to help you get the most out of your adhesive tape tensile test equipment. Our support team is ready to answer your questions, whether you need help with setup, calibration, or troubleshooting.
FAQs
- Find quick answers about our peel strength testers, pressure sensitive tape testing machines, and release liner peel testers.
- Learn about maintenance tips, recommended accessories, and software updates.
Downloads
- Access user manuals, calibration certificates, and software drivers anytime.
- Stay updated with the latest product brochures and compliance documents.
Contact Us
- For regional inquiries or personalized assistance, reach out via phone or email.
- We provide dedicated support tailored to your location and industry needs.
Need help now? Contact our expert team and get your adhesive bond strength analyzer running smoothly without delay.
Order Your Adhesive Tape Tensile Test Equipment Today
Ready to improve your tape testing process? Browse our related products below to find the perfect match for your quality control needs. From Peel Strength Testers to Release Liner Peel Testers and Pressure Sensitive Tape Testing machines, we’ve got you covered.
Explore More Products
- Adhesive Bond Strength Analyzers
- Packaging Tape Shear Testers
- Loop Tack Adhesion Instruments
- Universal Materials Testing Machines for Tapes
Don’t wait to boost your testing accuracy and efficiency. Request a quote now or contact our team for personalized assistance.
Start improving your tape testing quality with Dexiang—trusted by U.S. manufacturers for reliable and user-friendly adhesive tape tensile test equipment.
